Ash Street Rental Development

Vancouver, BC

Rezoning LCA (GBPR 2024) Wood Frame
LCA intensity (A–C)
0 kg CO2e/m²
Biogenic carbon (storage)
-0 kg CO2e
Structure
Wood frame + Concrete foundations

Project Overview

Six-storey rental MURB with wood-frame superstructure over two underground parking levels. The rezoning submission includes a whole-building LCA aligned to GBPR 2024, reporting compliance values (biogenic excluded) and separate biogenic storage for transparency.

The model (Athena IE 5.4) uses architectural take-offs, a 60-year life, and the required scope (substructure and shell). The building achieves an embodied carbon intensity of ≈ 358 kg CO2e/m² (A–C, biogenic excluded), with additional -139,516 kg CO2e of biogenic storage from wood products.

Ash Street rendering
Wood frame structure

Project Data

LocationAsh Street, Vancouver, BC
Building TypeRental MURB (Part 3)
StageRezoning (GBPR 2024)
Height / Parkade6 storeys; 2 underground levels
GFA (excl. parkade)≈ 5,414 m²
StructureWood frame superstructure; concrete substructure
LCA scopeA1–A5, B1–B5, C1–C4; 60-year life; Module D excluded
ToolAthena Impact Estimator 5.4
ComplianceAbsolute pathway (400 kg CO2e/m² benchmark)

Our Contribution

  • Whole-building LCA
  • Material take-offs coordination and Athena modeling
  • Rezoning permit documentation
  • CoV ECDR tables (condensed + detailed)
  • Compliance review and narrative
  • GBPR 2024 alignment

Key Results

Total GWP (A–C, excl. biogenic)≈ 1,936,018 kg CO2eIntensity: 358 kg CO2e/m²
A1–A5 (Product + Construction)≈ 1,713,749 kgMaterials, manufacturing, transport, installation
B1–B5 (Use stage)≈ 136,611 kgMaintenance and replacements
C1–C4 (End of life)≈ 85,658 kgDeconstruction and disposal
Biogenic carbon storage-139,516 kg CO2eInformational, reported separately
