Delta Mixed-Use Office

Delta, BC

Building Permit Energy Modeling Step Code 2
TEUI (modeled)
0 kWh/m²/yr
TEDI (modeled)
0 kWh/m²/yr
Childcare (NECB Part 8)
TEDI 0 kWh/m²/yr
Mixed-use area
0 m²

Project Overview

Five-storey mixed-use office building with four underground parking levels. Our scope covered Part 3 building energy modeling to demonstrate BC Energy Step Code 2 compliance for office, retail, and childcare occupancies.

The IES-VE 2023 model applied the weighted-average method across occupancies (per CoV EMG V2) and a separate NECB Part 8 reference for the childcare occupancy. Results: TEUI ≈ 127.6 and TEDI ≈ 34.6 (overall); childcare vs NECB: TEDI ≈ 82.3 (target =114) and TEUI ≈ 256 (target =342).

Delta Office rendering
Systems and rooftop units

Project Data

LocationDelta, BC
Building TypePart 3 Mixed-Use Office
StageBuilding Permit
Storeys / Parkade5 storeys; 4 underground levels
Total modeled floor area8,804 m²
Occupancy areasOffice 7,720 m²; Commercial 600 m²; Childcare 484 m²
SystemsVRF + ERVs (office/retail); RTU + ERV (childcare)
MethodWeighted-average (CoV EMG V2); childcare NECB Part 8 reference
ComplianceBCBC 2024 Part 10; Step Code 2 (all occupancies)
Childcare complianceNECB 2015 Part 8 performance path

Our Contribution

  • Whole-building energy modeling Weighted-average method across occupancies; NECB reference for childcare.
  • Compliance analysis Verified Step Code 2 targets with detailed TEDI/TEUI reporting.
  • Childcare modeling (NECB Part 8) Built separate NECB reference and proposed models for the childcare occupancy.
  • Permit documentation Prepared complete Part 3 energy modeling package for submission.

Key Results

TEUI (modeled)127.6 kWh/m²/yrTarget = 140.2
TEDI (modeled)34.6 kWh/m²/yrTarget = 39.2
GHGI (modeled)3.6 kg CO2e/m²/yrAll occupancies
Office/Retail TEDI28.7 kWh/m²/yrTarget = 30.0
Office/Retail TEUI111.8 kWh/m²/yrWeighted average
Childcare TEDI (NECB)82.3 kWh/m²/yrTarget = 114
Childcare TEUI (NECB)256 kWh/m²/yrTarget = 342
